Features

• Includes H-Base frame assembly, 54 in. columnmast, 3 ft. cantilever boom arm with winch bracket
• 60 ft. 3-way rescue retrieval SRL-R with mounting bracket
• 60 ft. material / personnel winch
• Removable legs for easy transportation and installation purpose.
• Multiple anchorage points for rescue applications.
• Foldable legs for easy transportation and installation purpose.
• Inbuilt swivel feature, davit column assembly can be rotated up to 360° by removing the locking pins provided to lock column.
• Material: High Strength and Durable Aluminum Alloy
• Opening of H-base: Minimum Opening Ø43.3 in. (1100mm) & Maximum Opening Ø59.44 in. (1500mm)
• Maximum Load Capacity: 1102 lbs. (500kgs)
• Finish: ED coated grey.
• System Strength: 15 kN (3300 lbs).
• Weight: 196.70 lbs ± 0.22 lbs (89.22kgs ± 0.10kgs).
• Relevant Standards: Conforms to EN795:2012 Type B, AS/NZS 5532:2013
